    Before you continue with the server installation, please make sure that you have the following components:

    JDK – the Java platform for your system http://www.oracle.com/technetwork/java/javase/downloads/jdk8-downloads-2133151.html
    MySQL – the database server https://dev.mysql.com/downloads/mysql/
    MySQL Client for database access

    1.Installing MySQL
    Installed MySQL 5.1. After installing, run the utility for MySQL Server Instance Configuration Wizard (she starts at the end of the installation if no – one can force from start-Programs-MySQL). Click Next until you see the fields with the password (Modify Security Settings).
    [​IMG]

    Set Navikat for MySQL. The program is paid, but there is a trial for a month, so don't piss. And crack to find, I think, will be no problem if desired. Run this program, press File > New Connection.

    [​IMG]

    Connection name - write something, then everything is filled with the default MySQL settings (I hope you did not change anything, but if you changed something here write something changed), the last line Password - write password that we entered in the settings of MySQL (for example, 12345). Click OK. In the left column of the main window Connections appeared the inscription Localhost_3306 (or some other numbers). Click twice on it to open the list. Now click the right button of the mouse on the same nadpisi, select New Database... and in the first line write lucera3.

    2.Preparing server settings files
    IF YOU DO NOT DO THIS ON THE SERVER WILL BE ABLE TO GET THE CONFIGURATION FILES AND WILL NOT START
    Go into the folder :

    authserver cmdlet\config\default
    gameserver\config\default

    Move the contents of folders in the root
    ------->

    authserver cmdlet\config\
    gameserver\config\

    3.Database Installation
    Database installation occurs exclusively via
    gameserver\sql\install.bat - before you run Install.bat/sh, YOU NEED to Configure access to the database in the file mysql_settings.bat/sh

    No Navicat speech and can not be - it does not work with procedures simply will not fill up the file items.sql
    In such cases you character will run around naked and not what an item will not be saved

    Код:
    @echo off

    set PATH="C:\Program Files\MySQL\MySQL Server 5.1\bin"<<<<<<<< Specify the installation directory the location of the MySQL server
    set USER=root<<<<<<<< the Username of the MySQL user
    set PASS=<<<<<<<< the Password of the MySQL user
    set DBNAME=lucear3<<<<<<<< the Name of the MySQL Database
    set DBHOST=localhost<<<<<<<< The host to connect to a MySQL database

    mysql-h %DBHOST% -u %USER% --password=%PASS% -Bse "use %DBNAME%" > nul 2>&1

    if errorlevel 9009 goto notfound
    if errorlevel 1 goto error
    goto end

    :error
    echo Can't use %DBNAME%!
    exit /b 1

    :notfound
    echo Can't find mysql binary!
    exit /b 1

    :END
    4.Configuring the Login server go authserver cmdlet\config\authserver cmdlet.properties
    LoginserverHostname = put Your IP interface.
    If You have a router or proxy, make routing on an interface.
    Port Forwarding or Virtual Server tab on the routers.
    Proxyfactory Ala StormWall itself throws routing and traffic will come only with a proxy.


    [​IMG]

    LoginHost = 127.0.0.1 In this column indicate what address to connect the server login to game server.
    Only with regard to the game server and login server. Usually 127.0.0.1 , if you Login and Game server are not on a different PC.

    Also include Auto-pickup servers
    AcceptNewGameServer = True

    or False and leave record
    INSERT INTO `gameservers` (`server_id`, `host`) VALUES(1, '192.168.1.12'); 192.168.1.12 < Change your from LoginHost =

    5.Setup Game server - go gameserver\config\server.properties
    In this parameter to indicate what address will connect's customers. If you server is running as a local area network and global - leave the star. If that would have worked in only in the global network put your external network address. Look it up on 2ip.ru
    GameserverHostname = *

    ExternalHostname = this field you specify Your external IP address

    InternalHostname= this field you specify Your IP address within the network. If You have no local network, leave 127.0.0.1
